ADD5110 Dual Reader Interface

ADD5110 Dual Reader Interface
If you are a registered Vanderbilt partner, please log in to see pricing.
Not a Vanderbilt customer? No problem, you can register here.
Need a Vanderbilt product installer? click here
  • Article number: V6FL7820-8CA11
  • EAN/UPC-Code: 4025515475088
Description Certificates Import & Export Resources Technical data Documentation
Description
Close menu
Product information "ADD5110 Dual Reader Interface"
The ADD5110 provides an interface between a card reader and the advanced central controller (AC5102 or AC5200) for up to two card readers. When a cardholder presents the access card at an entry or exit reader the ADD5110 reader interface interprets the encoded information and sends this data to the controller. The controller then checks the validity of the cardholder‚ and if the appropriate permissions have been assigned‚ the controller sends a message back to the reader interface allowing it to unlock the door and provide passage. It can also report the status of the door (locked or unlocked) at any time.
Certificates
Close menu
Import & Export
Gross weight (KG) 0.582
Purchase unit PCE
EAN/UPC-Code: 4025515475088
Minimum order 1
Country of origin HU
ECCN EAR99
Material code V6FL7820-8CA11
Net weight 0.553
Statistical code 84733020
Resources
This link will redirect you to the Value added resources section of our website where you can find information on product compatibilities, product lifecycle news, videos, marketing support materials, case studies, approvals and much more.
Technical data
Close menu
Operating voltage: 24 VDC ±20 %
Housing material: Plastic ABS
Interfaces: FLN connection to central controller: RS485 Connection to readers: RS485 bus for max 2 CerPass readers or 2 Clock & Data / Wiegand ports
Approval: CE
Weight: 0.55 kg
Housing: ABS plastic
Housing protection: IP55
Indicators: Power‚ Activity‚ Communication
Firmware: Flash upgradeable
Tamper switch: Optional‚ auxiliary input
Inputs: 1 x REX-button 1 x Door contact 3 x Auxiliary All inputs unsupervised or supervised
Outputs: 1 x Lock output relay (30 VDC‚ 2 A) 1 x Auxiliary relay (30 VDC‚ 2 A)
Power consumption: 25 W
Power output: Reader: 300 mA Ancillary: 1 A
Interface: FLN connection to controller: RS485 To reader: One RS485 bus for up to two RS485 readers (CerPass protocol) OR two Wiegand/Clock&Data ports
Dimensions (W x H x D): 150 x 150 x 76 (mm)
