VR40S-MF NGCR MIFARE EV1 Reader +keypad

Forhåndsvisning: VR40S-MF NGCR MIFARE EV1 Reader +keypad Forhåndsvisning: VR40S-MF NGCR MIFARE EV1 Reader +keypad Forhåndsvisning: VR40S-MF NGCR MIFARE EV1 Reader +keypad Forhåndsvisning: VR40S-MF NGCR MIFARE EV1 Reader +keypad
VR40S-MF NGCR MIFARE EV1 Reader +keypad
VR40S-MF NGCR MIFARE EV1 Reader +keypad
VR40S-MF NGCR MIFARE EV1 Reader +keypad
VR40S-MF NGCR MIFARE EV1 Reader +keypad

Log venligst ind for at se priser.
Ikke en Vanderbilt kunde? Intet problem,du kan registrere dig her.
Har du brug for et Vanderbilt-produktinstallatør ? klik her
  • Varenummer: V54504-F102-A100
  • EAN/UPC-Kode: 4025515469841
Beskrivelse Certificates Import og eksport Ressourcer Teknisk data Dokumentation Software nyttige links
Beskrivelse
Luk menu
Produkt information "VR40S-MF NGCR MIFARE EV1 Reader +keypad"
Designed for today’s bright, clean interiors, yet robust in service, the VR40S-MF is easy to install, use and maintain. The VR40S-MF has three indicator LEDs and a multi tone buzzer for audio verification. A multicolour light frame enforces access status information. This can be configured to follow the indicator LEDs, or any number of different options. It has a high quality backlight keypad with tactile feedback as well as a graphical OLED display to maximise user interaction with arming, access and recognition messaging etc., resulting in improved and enhanced user interaction “at the door”. Display brilliance is set automatically by an inbuilt light sensor.
Certificates
Luk menu
Import og eksport
Bruttovægt (KG) 0.65
Købs Enhed PCE
EAN/UPC-Kode: 4025515469841
mindste bestilling 1
Statistisk kode 84719000
ECCN EAR99
Oprindelsesland RO
Nettovægt 0.561
Materialekode V54504-F102-A100
Ressourcer
Dette link vil føre dig til vores ressource-side, som indeholder links til de mest gængse informationer omkring vores produkter, bland andet download centeret, hentning af brochurer, videoer, support og meget andet.
Teknisk data
Luk menu
Weight: 0.628kg
Housing material: Zinc casted metal bezel with polycarbonate plastic front
Operation temperature: -40°C to +55°C (surface mounted) -10°C to +55°C (back box mounted)
Keypad: Yes
Display: Yes, graphic monochrome OLED
Current consumption: DC 12V: 60mA (Max: 220mA) DC 24V: 40mA (Max 125mA)
Approval: CE according to R&TTE and EMC Directives; RED; FCC; UL (pending)
Air humidity (EN 60721): 5-95% non-condensing
Housing protection: IP55 (surface mounted) IP3X (back box mounted)
Impact rating: IK08
Indicators: 3 x LED (red/yellow/green); 1 x Buzzer; Multicolor light frame
Power consumption: DC 12V = 60mA (220mA Peak); DC 24V = 40mA (125mA Peak)
Card compatibility: MIFARE Classic; MIFARE Plus (UID only); MIFARE DESFire EV1; MIFARE DESFire EV2/EV3 (to EV1 conditions only)
Dimensions (W x H x D): Surface mounted: 85 x 114 x 22 (mm) ; Back box mounted: 85 x 114 x 14 (mm)
Environment: Indoor/outdoor use
Colour: Black, matt chrome
Card technology: MIFARE
Interface to controller: RS485 OSDP
Card read distance: Up to 6 cm
Tamper protection: Yes
Operating voltage: 8.5 ~ 30.0 VDC
Dokumentation
Luk menu
Software
Luk menu
nyttige links
