SPCG310.000 E-Bus Gateway

Wenn Sie Kunde von Vanderbilt sind, melden Sie bitte sich an, um Preise zu sehen.
Sie sind kein Vanderbilt-Kunde? Kein Problem, hier können Sie sich registrieren.
Suchen Sie einen Errichter für Vanderbilt-Produkte? Dann klicken Sie hier
  • V54554-A101-A100
  • 4025515471134
Tuotetiedot "SPCG310.000 E-Bus Gateway"
The SPCG310.000 E-BUS Gateway provides an interface between SPC X-BUS and Sintony E-BUS. The gateway enables the SPC controller to recognize Sintony peripheral devices by simulating the E-BUS devices so they appear to the SPC controller as X-BUS devices. The SPC controller supports up to five acre Intrusion E-Bus Gateways on its X-BUS. The maximum number of Sintony input zones supported by SPC is 252 and the maximum number of Sintony outputs is 174. The SPCG310.000 is supplied without housing. There are a number of housing options available. The acre Intrusion E-Bus Gateway can be mounted within the SPC controller housing, Sintony power supply units or in Sintony transponder housing.
Gross weight (KG) 0.08
Osta yksikkö PCE
EAN/UPC-Code: 4025515471134
Mindestabnahme 1
Statistical code 85311030
ECCN EAR99
Material code V54554-A101-A100
Net weight 0.076
Country of origin PH
Tamper contact: Tamper switch
Air humidity (EN 60721): Max. 90%rh, non-condensing
Dimensions (L x W x H): 52 x 92 x 13 (mm)
Tamper switch: Yes
Max. number of hardwired zones: 252 (Sintony Inputs)
Compatibility: - SAT12/SMT12 - SMT22 - SAT24/SMT24 - SMT44 - SAK41 - SAK51 - SAK53 - SAP08 - SAP14 - SAP20 - SAP25
Relative humidity: Max. 90% (non-condensing)
Weight: 0.020 kg
Operating temperature: -10 to +50 °C
Mounting: - SPC controller housing - Sintony transponder housing - Sintony PSU housing
Quiescent current: 40 mA
Operating current: 40 mA
Operating voltage: 9.5 - 14 V DC
Interfaces: X-BUS (In / Out) E-Bus
Approval: VdS Class C, SES, VSÖ (pending)
