ENC-010 Enclosure 490x530x142mm

Wenn Sie Kunde von Vanderbilt sind, melden Sie bitte sich an, um Preise zu sehen.
Sie sind kein Vanderbilt-Kunde? Kein Problem, hier können Sie sich registrieren.
Suchen Sie einen Errichter für Vanderbilt-Produkte? Dann klicken Sie hier
  • V6FL7820-8DA10
  • 4025515475149
Tuotetiedot "ENC-010 Enclosure 490x530x142mm"
Security cabinet to house the SiPass access control hardware. Designed in tandem with the hardware itself, the surface-mounted, single door enclosures ate purpose-built to provide secure housing while maximizing convenience of installation and operation. Cabinets feature multiple access points for cabling, an external LED to indicate the power status, a lockable door, an interior designed for holding Printed Circuit Boards and a finished, modern exterior. Three different sizes are available: small, medium and large. Even the smallest cabinet can house an Advanced Central Controller & Input Point Module, with plenty of space for peripherals like backup batteries and power supplies. The largest cabinet can house a combination of hardware unit types, making it ideal for large facilities with complex requirements. All cabinets are pre-assembled and shipped ready to install. Mounting points on the internal backplane and the chassis allow for quick and easy installation of PCBs and the enclosure itself.
Gross weight (KG) 12.34
Osta yksikkö PCE
EAN/UPC-Code: 4025515475149
Mindestabnahme 1
Country of origin US
Material code V6FL7820-8DA10
Statistical code 94032080
ECCN EAR99
Net weight 11.400
Dimensions (W x H x D): 49 x 53 x 14.2 (cm)
Tamper switch: Tamper input into ACC to detect unauthorized access
Housing material: Thick plate steel
Tamper contact: Tamper input into ACC to detect unauthorized access
LED Indicators: External LED to show the ACC Power on/off
