Product information "IS435 Aktiv-IR-Schrankenpaar. 60m"

Intelligent active infrared beams especially designed for perimeter protection. The synchronised and intelligent "twin" beams reinforce each other improving both range and stability in severe weather conditions. Use BP -60TE when pole mounted.

Close menu

Certificate (CE) - Issued by Vanderbilt, on 24/10/2018

Gross weight (KG)	1.175
Purchase unit	PCE
EAN/UPC-Code:	4025515475705
Minimum order	1
Statistical code	85311030
Material code	VBPZ:5299050001
Net weight	1.116
Country of origin	VN
ECCN	EAR99

This link will redirect you to the Value added resources section of our website where you can find information on product compatibilities, product lifecycle news, videos, marketing support materials, case studies, approvals and much more.

Close menu

Dimensions (W x H x D):	73 x 170 x 71.5 mm
Housing material:	Resina policarbonato (rosso vino)
Mounting:	Height 0.8 ~ 1.0 m
Weight:	0.380 kg transmitter 0.400 kg receiver
Operating temperature:	-25 ~ +60 °C
Frequency:	4 selectable channels
Current consumption:	80 mA
Tamper output contact rating:	30 V (AC/DC) < 0.5 A Transmitter and receiver covers
Housing:	PC resin (wine red)
Power supply:	12 ~ 30 VDC
Supply voltage:	12 ~ 30 VDC
Housing protection (EN 60529):	IP55
